Multivalve Extra 300/30 dx cylindrical



Multivalve angle:Normal 30°
Gas out diameter:8 mm
Hose side:On right
For tank with a diameter:300 mm
product code:70.TOM.786
manufacturer: TOMASETTO
category:Multivalves TOMASETTO
approval number: E8-67R-013018
Ask about the product
gross: 49,77
net: 40,46 €



Out of stock Shipping in:
5-7 days
Delivery from: 4



Added 1 pcs.
to cart!




X to cart
49,77

Multivalve Extra 300/30 dx cylindricalProduct code: 70.TOM.786


Copyrights and rules of photo use

Product description:

Multivalve for a cylindrical, cylindrical tank in the Extra version model AT02 from the Italian company Tomasetto Achille Spa.

Description of use:

Multi-function valve, fittings for LPG cylindrical tank, in the trunk of a vehicle for a tank with a diameter of 300 millimeters. It fulfills several important functions related to the safety and use of the gas system in the vehicle. He is responsible, among other things, for filling the tank with the right amount of gas, up to 80% of the tank's water capacity, transmitting a signal about the tank's filling level, protection against excessive pressure increase in the tank, protection against a sudden gas outflow caused by damage to the gas pipe between the tank and the engine compartment, shutting off gas outflow from the tank when the engine is turned off.

Technical specifications:

Multivalve 300/30ᵒ, for a tank with a diameter of 300 millimeters and a multivalve seat inclined 30ᵒ from the vertical, in the DX version with the hoses exiting the head to the right. Socket for a copper power cable with a nominal diameter of 8 millimeters with an external thread G1/8 ", and a socket for an output cable to the engine compartment with a nominal diameter of 8 millimeters with an internal thread M12x1 millimeter. Complete with wiring, and an assembly bag in which there are:
- 6 multi-valve mounting bolts,
- a barrel for a power cord with a diameter of 8 millimeters,
- a clamping nut with a G1/8" thread for a barrel with a diameter of 8 millimeters,
- a barrel for the output wire with a diameter of 8 millimeters,
- pressure screw with M12x1 millimeter thread for a barrel with a diameter of 8 millimeters.
Attention:
The set does not include a gas filler and a multi-valve housing.

Features:

Multivalve angle: Normal 30°
Gas out diameter: 8 mm
Hose side: On right
For tank with a diameter: 300 mm
