Power: | 204 HP |
---|---|
Input diameter: | 6 mm |
Electrovalve: | No |
Integrated filter: | No |
Temperature sensor: | No |
Reducer model | TUR6 |
product code: | 90.WAR.161 |
---|---|
manufacturer: | KME |
category: | Reducers KME |
manufacturer code: | Z350257 |
approval number: | P1 NSF Reg. 123000 |
Reducer, TUR6Z evaporator for sequential gas injection in the volatile phase of the Polish company KME.
an eductor used in gas injection installations, most often found with KME, Diego or Nevo installations. It also works with many other vapor phase gas injection control systems available on the market.
The TUR6Z reducer is with a toggle pressure regulation, the entrance for a copper pipe with a nominal diameter of 6 millimeters, the gas inlet socket for the reducer with an M10x1 millimeter thread, with a safety valve on the perimeter of the body, designed for engines with a rated power of up to 150kW (204KM).
External dimensions 142 millimeters by 130 millimeters and 82 millimeters thick.
The reducer comes complete with a mounting bracket with the necessary bolts and nuts, a sealing barrel with a diameter of 6 millimeters and a screw tightening the sealing barrel with an M10x1 millimeter thread.
